AP 3302 Pt. 3

Section 1

CHAPTER 1

PULSE-MODULATED RADAR



 measure the compass bearing of the target. North is used as the reference direction and bearings are given in degrees relative to North (Fig 16).

When the radar equipment is carried in a fighter aircraft the bearing of a target is given in degrees to port or starboard of the direction in which the fighter is heading (Fig 17).
